Fox 2.0 Performance Series 10.1in Remote Reservoir Front Shock for Select 2017-2026 Ford (4-5in Lift)

Fits select 2017-2026 Ford F-150, F-150 Lightning, F-250/F-350 Super Duty, Maverick, and Ranger models equipped with a 4-5 inch lift.

The Fox 2.0 Performance Series remote reservoir shock absorber delivers enhanced ride quality and the heat-dissipating capabilities required for intensive off-road use. The 2.0-inch metal-impacted 6061-T6 aluminum body is designed to dissipate heat significantly faster than conventional steel, while the external reservoir system increases oil and nitrogen capacity for consistent, fade-free damping during long-duration cycling. Inside, a race-developed high-flow piston and application-specific valving provide a predictable, connected feel that reduces vehicle sway and improves control on various terrains.

This smooth-body shock features an internal floating piston (IFP) to keep the high-pressure nitrogen gas separate from the shock oil, preventing aeration and ensuring the valving performs exactly as intended. The assembly includes CNC-machined black anodized aluminum components and a dedicated reservoir mounting clamp.

• Shock Series: 2.0 Performance Series
• Body Material: 6061-T6 clear-anodized aluminum
• Travel: 10.1 inches
• Reservoir: External remote reservoir with included aluminum clamp
• Internal Design: Monotube with Internal Floating Piston (IFP) separation
• Shaft: Hard chrome plated heat-treated alloy steel
• Finish: Clear-anodized for corrosion resistance
• Serviceability: Fully rebuildable and re-valvable
• Manufacturer Part Number: 985-24-163
