ICON 2.5 Series V.S. IR Rear Coilover Kit with Heavy Rate Springs for 2021-2023 Ford Bronco

Fits 2021-2023 Ford Bronco models including Badlands, Base, Big Bend, Black Diamond, Everglades, First Edition, Heritage Edition, Outer Banks, and Wildtrak.

The ICON Vehicle Dynamics V.S. 2.5 Series internal reservoir (IR) rear coilovers are engineered to enhance the suspension performance of the 2021-2023 Ford Bronco. This kit features heavy-rate, progressive dual-rate coil springs designed specifically for vehicles frequently carrying additional weight from bumpers, winches, or overland gear. The shaft-up orientation and vehicle-specific valving maximize rear wheel travel up to 14 inches while providing adjustable lift heights to accommodate larger tire packages.

Constructed with 2.5-inch diameter CAD-plated shock bodies and 7/8-inch induction-hardened shafts, these coilovers utilize 6061 aircraft-grade aluminum CNC-machined components for long-term durability. The 100% bolt-on design ensures a straightforward installation without the need for drilling or welding.

• Manufacturer Part Number: 48613
• Adjustable Rear Lift Height: 2-3" (Non-Sasquatch) or 1.25-2.25" (Sasquatch)
• Shock Body: 2.5" diameter CAD-plated steel
• Shaft: 7/8" diameter induction-hardened chrome plated
• Springs: ICON-engineered heavy-rate dual-rate progressive springs
• Bearings: FK rod end bearings for minimal deflection
• Installation: 100% Bolt-on; no cutting or welding required
• Serviceability: Fully rebuildable and re-tunable design
