The Injector Dynamics 2600-XDS series represents the standard for high-flow fuel delivery in extreme performance applications. Designed to handle massive fuel requirements while maintaining excellent idle and cruise characteristics, these injectors are an essential component for high-output builds running E85 or other ethanol-based fuels. This matched set of four provides the consistency and reliability required for precision tuning and engine safety.

• Manufacturer Part Number: 2600.48.14.14B.4
• Series: 2600-XDS
• Injector Length: 48mm (O-ring to O-ring)
• Inlet Diameter: 14mm
• Outlet/Adapter Diameter: 14mm
• Quantity: Set of 4 matched injectors

Each injector is rigorously tested to ensure linear flow rates and consistent dead-time characteristics across the entire operating range. The included 14mm top and bottom adapters allow for a drop-in fit for specific fuel rail and intake manifold configurations, ensuring a leak-free seal and optimal spray pattern orientation.

The Injector Dynamics 2600-XDS series is engineered to provide precise fuel delivery for high-horsepower forced induction and alternative fuel applications. These injectors offer exceptional flow stability and atomization, maintaining consistent performance even at low pulse widths. Built with stainless steel internals, the 2600-XDS is fully compatible with gasoline, ethanol, and methanol, ensuring long-term reliability in demanding fuel systems.

This matched set of eight injectors features a 48mm nominal length (O-ring to O-ring) and 14mm diameter O-rings on both the fuel rail and manifold ends for secure sealing. Each injector is part of a flow-matched set to ensure balanced cylinder performance, which is critical for high-output tuning and engine longevity. This set serves as a direct replacement or upgrade for fuel systems requiring these specific physical dimensions.

• Manufacturer Part Number: 2600.48.14.14.8
• Series: 2600-XDS
• Length: 48mm
• Top O-Ring: 14mm
• Lower O-Ring: 14mm
• Quantity: Set of 8 Injectors
• Internal Material: Stainless Steel

The Injector Dynamics 2600-XDS provides extreme flow rates with the low-pulse-width stability required for precise high-performance tuning. As the successor to the ID2000, the 2600-XDS features an improved internal design for better atomization and superior control at high fuel pressures. These injectors are engineered with materials compatible with all known automotive fuels, including E85 and methanol.

Every set is pressure-tested and flow-matched to ensure consistent cylinder-to-cylinder fuel delivery, critical for high-horsepower engines. This specific 48mm length configuration utilizes 14mm upper and lower O-rings, designed to fit many common aftermarket and factory fuel rail applications.

• Manufacturer Part Number: 2600.48.14.14.6
• Injector Series: 2600-XDS
• Body Length: 48mm (O-ring to O-ring)
• Upper O-Ring Diameter: 14mm
• Lower O-Ring Diameter: 14mm
• Quantity: Set of 6 matched injectors
• Fuel Compatibility: All known automotive fuels (E85, Gasoline, Methanol)

The Injector Dynamics 2600-XDS series represents the peak of high-flow fuel delivery, engineered specifically for high-pressure applications where stability and precision are critical. This set of four injectors provides a massive flow rate while maintaining the control and consistency required for refined idle and low-load drivability.

• Product Line: 2600-XDS
• Length: 48mm (between o-ring centers)
• O-Ring Diameter: 14mm upper and 14mm lower
• Quantity: Matched set of 4
• Performance: Optimized for high-pressure fuel systems and compatible with all known automotive fuels
• Manufacturer Part Number: 2600.48.14.14.4

Each injector is meticulously characterized to ensure a perfect match across the set, simplifying the tuning process and protecting your engine from cylinder-to-cylinder fuel variance. These 48mm length injectors are designed to fit 14mm fuel rails and intake bungs commonly found in performance applications.

Designed for high-horsepower applications requiring maximum fuel delivery without compromising idle quality, the Injector Dynamics 2600-XDS series provides precision flow control for demanding builds. This set of four injectors features a 48mm length and 11mm top, specifically equipped with WRX bottom adapters for a direct-fit solution in compatible Subaru fuel rail configurations.

The 2600-XDS series is engineered to provide consistent atomization and linear flow even at high pressures and duty cycles. This makes them an essential upgrade for forced induction or ethanol-based fuel systems where standard injectors fall short. Each injector is part of a flow-matched set to ensure cylinder-to-cylinder consistency, critical for engine longevity and tuning precision.

• Product Line: 2600-XDS
• Length: 48mm
• Top O-Ring: 11mm
• Adapter: WRX Bottom Adapter
• Quantity: Set of 4
• Manufacturer Part Number: 2600.48.11.WRX.4

This set of eight Injector Dynamics 2600-XDS fuel injectors provides precision fuel delivery for high-output engines. The XDS series is engineered to provide consistent atomization and refined low-pulse-width control, which is essential for maintaining smooth idle and drivability in high-horsepower applications.

Each injector is built to strict tolerances and features a 34mm length, equipped with a 14mm top O-ring and a 15mm lower O-ring to ensure a secure, leak-free seal within compatible fuel rails and intake manifolds. As with all Injector Dynamics components, these are matched sets to provide uniform flow across the entire engine bank.

• Series: 2600-XDS
• Quantity: Set of 8
• Length: 34mm
• Top O-Ring: 14mm
• Lower O-Ring: 15mm
• Manufacturer Part Number: 2600.34.14.15.8

The Injector Dynamics 2600-XDS series represents the pinnacle of high-flow fuel delivery, engineered for extreme performance applications requiring precise fuel metering and superior atomization. These injectors are specifically designed to provide consistent performance across a wide range of pulse widths, ensuring stable idling even on high-output builds.

• Series: 2600-XDS
• Length: 34mm (O-ring to O-ring)
• Inlet O-Ring: 14mm
• Outlet O-Ring: 14mm
• Quantity: Matched Set of 6
• Manufacturer Part Number: 2600.34.14.14.6

This set features a compact 34mm length and 14mm O-rings on both the top and bottom, facilitating a secure fit in compatible aftermarket fuel rails and intake manifolds. Each set is flow-matched to tight tolerances to ensure balanced cylinder-to-cylinder fueling and simplified tuning.

The Injector Dynamics 2600-XDS is the most advanced high-flow injector available, engineered specifically for high-output applications requiring extreme fuel delivery. This matched set of four provides exceptional flow consistency and superior idle control, bridging the gap between massive power and streetable drivability. Built with a stainless steel internal flow path, the XDS series is designed to withstand the corrosive nature of E85, methanol, and oxygenated fuels.

• Manufacturer Part Number: 2600.34.14.14.4
• Product Series: 2600-XDS
• Injector Length: 34mm
• Top O-Ring Diameter: 14mm
• Lower O-Ring Diameter: 14mm
• Quantity: Matched Set of 4
• Compatible with all known automotive fuels

The Injector Dynamics 2600-XDS is the highest-flowing injector in the ID lineup, engineered to provide reliable and precise fuel delivery for high-performance engines. Developed specifically for use with gasoline, ethanol, and methanol, these injectors utilize advanced internal components to deliver exceptional low-pulse-width linearity and consistent flow rates across all injectors in the set.

This pair features a compact 34mm body length and 14mm O-rings on both the top and bottom, ensuring a secure fit in specific aftermarket fuel rail and manifold configurations. They are designed to meet the demands of forced induction and extreme naturally aspirated builds requiring high fuel volume and absolute spray precision.

• Manufacturer Part Number: 2600.34.14.14.2
• Product Series: 2600-XDS
• Body Length: 34mm
• Upper O-Ring Diameter: 14mm
• Lower O-Ring Diameter: 14mm
• Quantity: Set of 2
• Fuel Compatibility: Gasoline, Ethanol, and Methanol

The Injector Dynamics 2600-XDS Fuel Injector set provides professional-grade fuel delivery for high-demand performance applications. This set of 10 injectors features the XDS series design, which is engineered for superior pulse-width linearity and consistent flow across the entire operating range. With a compact 34mm length and standard 14mm O-rings, these units are designed to seat precisely in fuel rails and manifolds requiring these specific fitment dimensions.

• Complete set of 10 matched fuel injectors
• XDS technology for enhanced low-flow control and tuning stability
• Compact 34mm length for specific rail-to-manifold spacing
• 14mm top O-ring and 14mm lower O-ring configuration
• Manufacturer Part Number: 2600.34.14.14.10

Fits 1979-1986 Mazda RX-7.

This set of two Injector Dynamics 2600-XDS fuel injectors is engineered for high-output applications requiring precise fuel metering and exceptional flow capacity. The XDS series represents the pinnacle of large-flow injector technology, providing the stable idle and consistent low-pulse-width performance necessary for street-driven or track-focused rotary engines. Built to withstand the demands of modern fuels, these injectors are fully compatible with gasoline and high-ethanol blends.

This specific kit is configured for the early RX-7 fuel rail, featuring 14mm top adapters and -204 / 14mm lower O-rings to ensure a leak-free seal and direct fitment. Whether you are upgrading your primary or secondary rail, these injectors deliver the linearity and atomization required for forced induction or high-performance naturally aspirated builds.

• Manufacturer Part Number: 2600.11.06.60.14.2
• Series: 2600-XDS
• Top Adapter: 14mm
• Lower O-Ring: -204 / 14mm
• Quantity: Set of 2 Injectors
• Compatibility: Compatible with all known fuels including E85

This set of six high-performance Injector Dynamics 1340cc fuel injectors is engineered for applications requiring precise fuel metering and superior atomization. These injectors provide exceptional low-pulse-width linearity, making them an ideal choice for high-horsepower builds that still require smooth idle and part-throttle characteristics.

Built to exacting standards, these injectors feature a 60mm length (O-ring to O-ring) and come equipped with 14mm purple adapter tops for secure fuel rail fitment. The included Denso lower cushions ensure a reliable seal at the intake manifold to prevent vacuum leaks and maintain consistent combustion pressure. These components are designed to withstand the rigors of performance tuning while maintaining flow-matched accuracy across the entire set.

• Flow Rate: 1340cc/min
• Length: 60mm
• Top Diameter: 14mm (Purple Adapter Top)
• Lower Seal: Denso Lower Cushion
• Quantity: Set of 6 matched injectors
• Manufacturer Part Number: 1300.60.14.D.6

This matched set of eight Injector Dynamics 1340cc fuel injectors is designed for high-performance applications requiring precise fuel metering and exceptional atomization. These injectors provide a linear flow range that remains consistent even at low pulse widths, ensuring smooth idle and drivability in high-horsepower builds. Built with stainless steel internals, they are fully compatible with all known fuels, including E85 and alcohol-based blends.

• Flow Rate: 1340cc/min nominal
• Length: 60mm (O-ring to O-ring)
• Top O-Ring Diameter: 14mm (Grey Top)
• Bottom Adapter: Blue Bottom Adaptor
• Quantity: Matched Set of 8
• Manufacturer Part Number: 1300.60.14.14B.8

Each set is dynamically flow-matched to provide uniform fuel delivery across all cylinders, simplifying the tuning process and ensuring engine safety under high-load conditions.

The Injector Dynamics ID1300X is a high-output fuel injector designed for high-performance applications that require precise fuel delivery and compatibility with various fuel types. This specific set includes four injectors pre-configured with 14mm grey top adapters and 14mm silver lower o-rings for a secure, leak-free installation in matching fuel rails and intake manifolds.

Built with all-stainless internals, the ID1300X series is engineered to withstand the corrosive nature of alcohol-based fuels like E85 while maintaining exceptional idle and cruise behavior. These injectors are the result of a collaboration between Injector Dynamics and Bosch, ensuring high-pressure capability and consistent flow rates across the entire set.

• Manufacturer Part Number: 1300.60.14.14B.4
• Product Series: ID1300X
• Top Adapter: 14mm (Grey)
• Lower O-Ring: 14mm (Silver)
• Quantity: Set of 4 Injectors
• Internals: All-Stainless Steel
• Fuel Compatibility: All known automotive fuels (Gasoline, Ethanol, Methanol)

This set of eight Injector Dynamics 1340cc fuel injectors (MPN 1300.60.14.14.8) provides precise fuel delivery for high-performance applications requiring increased flow capacity. These injectors are configured with a 60mm length and feature 14mm purple top adapters along with 14mm lower O-rings to ensure a proper seal in compatible fuel rails and intake manifolds.

• Flow Rate: 1340cc/min
• Length: 60mm (O-ring to O-ring)
• Inlet: 14mm Purple Top Adapter
• Outlet: 14mm Lower O-ring
• Quantity: Matched Set of 8
• Manufacturer Part Number: 1300.60.14.14.8

This set of six Injector Dynamics 1300 Series fuel injectors provides a flow rate of 1340cc/min, engineered for high-output engines requiring precise fuel delivery. These injectors feature corrosion-resistant stainless steel internals, making them compatible with all known fuels, including gasoline, ethanol (E85), and methanol.

Built to provide exceptional idle quality and consistent flow matching across all six units, these injectors solve the tuning challenges often found with large-capacity fuel systems. This configuration uses a 60mm overall length with 14mm purple top adapters and 14mm lower o-rings for a precise fit in factory or aftermarket fuel rails.

• Flow Rate: 1340cc/min
• Injector Length: 60mm (O-ring to O-ring)
• Upper Adapter: 14mm Purple Top
• Lower O-Ring: 14mm
• Internal Construction: Stainless Steel
• Compatibility: All known fuels (Gasoline, E85, Methanol)
• Quantity: Matched Set of 6
• Manufacturer Part Number: 1300.60.14.14.6

The Injector Dynamics ID1300x is a high-performance fuel injector designed specifically for motorsport applications. Developed in collaboration with Bosch Motorsport, these injectors feature all-stainless internals, making them fully compatible with all known fuels, including E85 and other corrosive alcohol-based blends.

This set of four 1340cc injectors provides exceptional idle quality and predictable flow at high pressures. Each injector is measured for flow and latency across multiple data points to ensure a perfectly matched set for your engine. The 60mm length and 14mm upper and lower O-rings ensure a secure fit in compatible fuel rails and intake manifolds.

• Nominal Flow Rate: 1340cc/min @ 3.0 bar (43.5 psi)
• Length: 60mm (O-ring to O-ring)
• Inlet O-Ring: 14mm (Purple Top)
• Outlet O-Ring: 14mm
• Construction: All-stainless internals for maximum corrosion resistance
• Included: Set of 4 injectors with required O-rings
• Manufacturer Part Number: 1300.60.14.14.4

This set of two Injector Dynamics fuel injectors provides a nominal flow rate of 1340cc/min, engineered for high-output applications requiring precise fuel metering and superior atomization. These high-impedance injectors feature a 60mm length and 14mm purple tops, designed to offer stable performance even at low pulse widths for consistent idle and drivability.

• Flow Rate: 1340cc/min
• Length: 60mm (O-ring to O-ring)
• Top O-Ring: 14mm (Purple Top)
• Lower O-Ring: 14mm
• Quantity: Set of 2
• Manufacturer Part Number: 1300.60.14.14.2

Constructed for compatibility with various fuel types, including gasoline and ethanol, these injectors replace restrictive factory units to support increased power demands. The 14mm lower O-ring ensures a proper seal in compatible fuel rail and manifold bores.

This set of six Injector Dynamics 1340cc fuel injectors is engineered for high-performance applications requiring precision fuel delivery and superior atomization. Each injector is match-balanced to ensure consistent flow across all cylinders. These injectors feature a 60mm length and are equipped with 11mm blue top adapters and Denso lower cushions for a secure fit in compatible fuel rails and intake manifolds.

• Flow Rate: 1340cc/min
• Length: 60mm (O-ring to O-ring)
• Top Adapter: 11mm Blue Top
• Lower Seal: Denso Lower Cushion
• Quantity: Set of 6
• Manufacturer Part Number: 1300.60.11.D.6

Upgrade your fuel system with this set of four Injector Dynamics 1340cc injectors, engineered for precise delivery and consistent performance in high-output applications. These injectors are designed to provide the linear response required for a stable idle and accurate fueling across the entire RPM range, making them a preferred choice for professional tuners.

This specific configuration features a 60mm length (measured o-ring to o-ring) and an 11mm blue top adapter. The inclusion of the Denso-style lower cushion ensures a proper seal and secure fitment in compatible intake manifolds. Every set is flow-matched to tight tolerances to ensure cylinder-to-cylinder consistency.

• Flow Rate: 1340cc/min
• Injector Length: 60mm
• Top Diameter: 11mm (Blue Top)
• Lower Interface: Denso Lower Cushion
• Quantity: Matched Set of 4
• Manufacturer Part Number: 1300.60.11.D.4

Upgrade your fuel system with this precision-matched set of six Injector Dynamics 1340cc fuel injectors. Engineered for high-performance applications, these injectors provide the linear fuel delivery and exceptional atomization required for stable idling and consistent power under high boost or high-RPM conditions. This specific configuration utilizes a 60mm length with an 11mm blue top inlet adapter and a 14mm lower o-ring to meet specific fuel rail and manifold fitment requirements.

• Flow Rate: 1340cc/min
• Length: 60mm (O-ring to O-ring)
• Inlet Diameter: 11mm (Blue Top)
• Outlet Diameter: 14mm (Lower O-Ring)
• Quantity: Matched Set of 6
• Manufacturer Part Number: 1300.60.11.14.6

This set of four Injector Dynamics 1340cc fuel injectors (MPN 1300.60.11.14.4) is engineered for high-output applications requiring precise fuel metering and exceptional atomization. These injectors provide consistent performance across a wide range of pulse widths, ensuring idle stability without sacrificing top-end flow. Constructed with stainless steel internals, they are fully compatible with all known fuels, including gasoline, E85, and alcohol-based blends.

• Manufacturer Part Number: 1300.60.11.14.4
• Flow Rate: 1340cc/min at 3.0 Bar (43.5 psi)
• Length: 60mm (O-ring to O-ring)
• Inlet Diameter: 11mm (Blue Top)
• Outlet Diameter: 14mm Lower O-ring
• Corrosion Resistance: Full stainless steel internal construction
• Quantity: Matched set of 4

The 60mm length and 11mm/14mm o-ring configuration is designed to fit specific high-performance fuel rails and intake manifolds. Every set is flow-matched to tight tolerances to ensure uniform cylinder-to-cylinder fuel distribution, which is critical for engine safety and tuning precision in forced induction or high-compression builds.

This set of six high-performance Injector Dynamics fuel injectors provides a 1340cc flow rate for demanding fuel systems. Engineered for exceptional idle and cruise behavior while supporting significant power levels, these injectors offer the precision and consistency required for modern engine management.

The configuration features a 48mm length (O-ring to O-ring) with 14mm grey tops and a 14mm lower O-ring. This specific kit includes the R35 low spacer, making it an ideal fuel delivery upgrade for the Nissan GT-R VR38DETT platform.

• Manufacturer Part Number: 1300.48.14.R35.6
• Flow Rate: 1340cc/min at 3.0 bar (43.5 psi)
• Body Length: 48mm
• Inlet Diameter: 14mm (Grey Top)
• Outlet Diameter: 14mm Lower O-Ring
• Includes specialized R35 low spacers
• Dynamic flow matching for cylinder-to-cylinder consistency
• Set of 6 matched injectors

Upgrade your fuel system with this precision-engineered set of eight Injector Dynamics 1340cc fuel injectors. These high-performance injectors are designed for consistent fuel delivery and superior atomization in demanding motorsport and street applications. This specific configuration features a 48mm length and a 14mm grey top, combined with a 15mm orange low o-ring for a secure fitment in compatible fuel rails.

• Flow Rate: 1340cc/min
• Length: 48mm (O-ring to O-ring)
• Top Diameter: 14mm (Grey Top)
• Lower O-Ring: 15mm (Orange Low O-Ring)
• Quantity: Matched set of 8
• Manufacturer Part Number: 1300.48.14.15.8

This set of eight Injector Dynamics fuel injectors provides a 1340cc/min flow rate, engineered to deliver precise fuel metering for high-output engines. Designed to bridge the performance gap between the ID1050x and ID1700x series, these injectors offer exceptional low-pulse-width linearity and pressure capability. This specific configuration features a 48mm length (O-ring to O-ring) equipped with 14mm top O-rings and 14mm black bottom adaptors for a secure seal in compatible fuel rails and intake manifolds.

• Flow Rate: 1340cc/min at 3.0 bar (43.5 psi)
• Length: 48mm
• Top O-Ring: 14mm
• Bottom Adaptor: 14mm (Black)
• Quantity: Set of 8
• Manufacturer Part Number: 1300.48.14.14B.8

This set of four Injector Dynamics 1340cc fuel injectors is engineered for high-performance applications requiring precise fuel delivery and exceptional atomization. Featuring a 48mm overall length and 14mm O-rings, these injectors are equipped with a 14mm black bottom adapter to ensure a secure fit in compatible fuel rails and intake manifolds.

Constructed with all-stainless internals, these injectors offer superior corrosion resistance, making them fully compatible with E85 and other alcohol-based fuels. Each set is flow-matched to tight tolerances to ensure consistent cylinder-to-cylinder performance, which is critical for maintaining engine safety and tuning stability under high load.

• Flow Rate: 1340cc/min at 3.0 bar (43.5 psi)
• Injector Length: 48mm (O-ring to O-ring)
• Inlet O-Ring: 14mm
• Outlet O-Ring: 14mm (with Black Bottom Adapter)
• Internals: All-Stainless Steel
• Quantity: Matched Set of 4
• Manufacturer Part Number: 1300.48.14.14B.4

Upgrade your fuel system with this precision-matched set of 8 Injector Dynamics 1340cc fuel injectors. The ID1300-XDS series is designed for high-performance applications, featuring all-stainless internals for full compatibility with all known fuels, including E85 and ethanol-based blends. These injectors provide exceptional idle and cruise behavior while delivering the volume required for forced induction and high-horsepower builds.

• Flow Rate: 1340cc/min at 3.0 bar (43.5 psi)
• Injector Length: 48mm (O-ring to O-ring)
• Top O-Ring: 14mm (Grey)
• Lower O-Ring: 14mm
• Construction: Stainless steel internals for corrosion resistance
• Quantity: Set of 8 matched injectors
• Manufacturer Part Number: 1300.48.14.14.8

This matched set of six Injector Dynamics ID1300x fuel injectors is engineered for high-performance applications requiring precise fuel delivery and E85 compatibility. Developed through a partnership with Bosch Motorsport, the ID1300x series features all-stainless internals, making it highly resistant to the corrosive nature of alcohol-based fuels.

Each injector in this set is flow-matched to exacting standards, ensuring consistent cylinder-to-cylinder performance across the entire pulse width range. With a 48mm nominal length and 14mm grey top adapters, these units are designed to bolt into specific aftermarket and factory fuel rail configurations providing a reliable, leak-free seal.

• Manufacturer Part Number: 1300.48.14.14.6
• Flow Rate: 1340cc/min at 3.0 bar (43.5 psi)
• Length: 48mm (O-ring to O-ring)
• Upper O-Ring/Adapter: 14mm (Grey)
• Lower O-Ring: 14mm
• Internal Construction: All-stainless steel internals
• Quantity: Matched set of 6

Upgrade your vehicle's fueling system with this precision-matched set of four Injector Dynamics 1340cc fuel injectors. Engineered for high-performance applications, these injectors deliver exceptional atomization and consistent flow rates across a wide pulse-width range, ensuring better idle quality and tuning stability for forced induction or high-output builds.

This specific configuration features a 48mm length and 14mm grey tops to suit specific fuel rail and manifold requirements. Each set is rigorously tested and matched to provide uniform fuel delivery across all cylinders, reducing the risk of lean conditions under load.

• Flow Rate: 1340cc/min
• Length: 48mm (O-ring to O-ring)
• Inlet Diameter: 14mm (Grey Top)
• Outlet Diameter: 14mm (Lower O-Ring)
• Quantity: Matched set of 4
• Manufacturer Part Number: 1300.48.14.14.4

This set of two Injector Dynamics 1300cc fuel injectors is engineered for high-output applications requiring precise fuel metering and exceptional atomization. With a 48mm length and 14mm O-rings on both the top and lower seats, these injectors provide a secure fit in compatible high-performance fuel rails and intake manifolds. Each injector is manufactured to provide linear flow and consistent performance across the pulse width range, making them an essential upgrade for forced induction or high-compression builds.

• Flow Rate: 1300cc/min
• Length: 48mm
• Top O-Ring Diameter: 14mm
• Lower O-Ring Diameter: 14mm
• Quantity: Set of 2
• Manufacturer Part Number: 1300.48.14.14.2
