ARB Old Man Emu BP-51 Heavy Suspension Kit with UCAs for 2008-2021 Toyota Land Cruiser (LCBP51HP)

Fits 2008-2021 Toyota Land Cruiser (Base and Heritage Edition).

The ARB Old Man Emu BP-51 (Bypass 51mm) Heavy Kit brings race-bred internal bypass technology to the Toyota 200-series chassis. Engineered specifically for vehicles equipped with heavy accessories like steel bumpers, winches, and drawer systems, these position-sensitive shock absorbers provide a refined ride during normal travel while delivering significant end-zone damping for maximum chassis control off-road. The internal bypass ports allow oil to bypass the piston at ride height for comfort, while the remote reservoir design increases oil capacity to prevent fade during high-intensity use.

Each BP-51 shock is constructed from 6061 T6 aluminum with a Type 3 40-micron hard-anodized finish, providing superior heat dissipation and resistance to corrosion and stone damage. This kit includes heavy-duty upper control arms to ensure proper alignment geometry and maximize wheel travel. Damping is easily adjustable for both rebound and compression, allowing you to custom-tune the suspension for specific loads and terrain.

• Manufacturer Part Number: LCBP51HP
• 51mm diameter bore with position-sensitive internal bypass technology
• 6061 T6 aluminum shock bodies, reservoirs, and components
• Type 3 40-micron hard-anodized finish for maximum durability
• 6061 grade aluminum top hats and remote reservoir mounting hardware included
• Independent, wide-range adjustment for rebound and compression damping
• Includes upper control arms (UCAs) to maintain factory-spec alignment
• Designed to bolt onto factory mounting points without vehicle modifications
