Old Man Emu BP-51 Heavy Suspension Lift Kit for 2008-2021 Toyota Land Cruiser w/ KDSS (OMELC08BP51HK)

Fits 2008-2021 Toyota Land Cruiser Base and Heritage Edition models equipped with KDSS.

The Old Man Emu BP-51 (Bypass 51mm diameter bore) suspension system brings race-proven bypass technology to the Toyota Land Cruiser 200 Series. Developed and tested in the Australian Outback, these position-sensitive shock absorbers feature internal bypass ports that allow oil to bypass the piston at ride height for a plush feel, while increasing damping force at the ends of the stroke for superior bottom-out control. This "Heavy" kit is specifically engineered to maintain ride height and handling performance on vehicles equipped with significant additional weight, such as steel bumpers, winches, and drawer systems.

Constructed from 6061 T6 aluminum with a Type 3 40-micron hard-anodized finish, the shock bodies and remote reservoirs offer exceptional heat dissipation and corrosion resistance. The system is fully adjustable for both rebound and compression, allowing drivers to tune the damping to match their specific vehicle load and terrain requirements. This kit is designed for a direct bolt-on installation using factory mounting points, requiring no permanent vehicle modifications.

• Bypass 51mm (BP-51) internal bypass technology for position-sensitive damping
• Adjustable compression and rebound settings for custom-tuned ride quality
• High-grade 6061 T6 aluminum construction for maximum heat dissipation
• Type 3 40-micron hard-anodized finish for superior protection against stone damage and corrosion
• Remote reservoirs maintain oil volume and prevent shock fade during high-speed off-road use
• Specifically tuned for LC200 models with Kinetic Dynamic Suspension System (KDSS)
• Manufacturer Part Number: OMELC08BP51HK
