ICON Stage 5 0-3" Suspension System with Tubular UCAs for 1995-2004 Toyota Tacoma (K53015)

Fits 1995-2004 Toyota Tacoma models including Base, DLX, Limited, Pre Runner, S-Runner, and SR5.

The ICON Stage 5 Suspension System is engineered for the 1995-2004 Toyota Tacoma driver demanding maximum damping performance and wheel travel. This system features 2.5 Series front coilovers equipped with remote reservoirs for increased oil volume and heat dissipation, alongside ICON’s CDC (Compression Damping Control) Valve. The CDC Valve provides 10 user-adjustable compression settings, allowing you to fine-tune the ride for varying vehicle loads or terrain conditions. To ensure proper suspension geometry at 0-3" of lift, this kit includes tubular upper control arms (UCAs) featuring the patented Delta Joint, which provides the high-angle performance of a uniball with the weather resistance of a sealed ball joint.

For the rear, ICON utilizes 2.0 Aluminum Series remote reservoir shocks and a specific Add-A-Leaf kit. This leaf replaces the factory overload spring, effectively lowering the rear spring rate by approximately 10% to achieve a more compliant ride while providing 1.5" of rear lift. The entire system is a 100% bolt-on solution designed to improve both on-road stability and off-road capability.

• Front Lift Height: Adjustable from 0-3"
• 2.5 Series Front Coilovers with 7/8" shafts and remote reservoirs
• 10-setting CDC Valve for precise compression damping adjustment
• Tubular UCAs with patented Delta Joint (U.S. Pat. 10,731,700)
• 2.0 Aluminum Series rear shocks with 5/8" shafts and remote reservoirs
• Rear Add-A-Leaf kit for 1.5" lift and improved compliance
• Corrosion-resistant CAD plated coilover bodies and 6061 CNC machined components
• FK Rod End bearings for maximum durability and reduced deflection
• Complete bolt-on installation; no cutting or welding required
• Manufacturer Part Number: K53015
